HPE Modular Smart Array 2062 10GBase-T iSCSI SFF Storage
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
Quick Details
|
---|
|
HPE Modular Smart Array 2062 10GBase-T iSCSI SFF Storage
- Hard drive array
- 3.84 TB
- 24 bays (SAS-3)
- SSD 1.92 TB x 2
- iSCSI (10 GbE) (external)
- rack-mountable
- 2U
Additional Details | |
---|---|
Price: | |
Mfr Part #: | R7J71B |
SHI Part #: | 45380333 |
Category: | Disk arrays |
UNSPSC: | 43201802 |
Manufacturer: | Hewlett Packard Enterprise |
Product Type: | Hardware |
General Information | |
---|---|
Category | Disk arrays |
Description | HPE Modular Smart Array 2062 10GBase-T iSCSI SFF Storage - Hard drive array - 3.84 TB - 24 bays (SAS-3) - SSD 1.92 TB x 2 - iSCSI (10 GbE) (external) - rack-mountable - 2U |
Manufacturer | Hewlett Packard Enterprise |
UNSPSC | 43201802 |
Main Specifications | |
Dimensions & Weight / Depth | 50.8 cm |
Dimensions & Weight / Height | 8.9 cm |
Dimensions & Weight / Weight | 5 kg |
Dimensions & Weight / Width | 44.5 cm |
Hard Drive / Capacity | 1.92 TB |
Hard Drive / Interface | Serial Attached SCSI 3 |
Hard Drive / Interface Type | Serial Attached SCSI 3 |
Header / Brand | HPE |
Miscellaneous / Product Color |
|
Packaged Quantity | 1 |
Service & Support / Type | 3-year warranty |
Storage / HDD Array External Interface | iSCSI (10 GbE) |
Storage / HDD Array External Interface Class | iSCSI |
Storage / Rack-mountable | Rack-mountable |
Storage / Total Array Capacity | 3.84 TB |
Storage / Type | Hard drive array |
Chassis | |
Installed Devices / Modules Qty | 2 |
Supported Devices / Modules Qty | 24 |
Supported Drives | SAS-3 |
Dimensions & Weight | |
Depth | 50.8 cm |
Height | 8.9 cm |
Weight | 5 kg |
Width | 44.5 cm |
Environmental Parameters | |
Max Operating Temperature | 40 °C |
Min Operating Temperature | 5 °C |
Sound Emission | 74 dBA |
Environmental Standards | |
ENERGY STAR Certified | Yes |
Expansion / Connectivity | |
Expansion Bays | 24 (total) / 22 (free) - 2.5" SFF |
Interfaces |
|
General | |
Device Type | Hard drive array |
Enclosure Type | Rack-mountable - 2U |
Hard Drive | |
Capacity | 2 x 1.92 TB |
Features | Read Intensive |
Interface Type | SAS 12Gb/s |
Type | SSD - hot-swap |
Manufacturer Warranty | |
Service & Support | Limited warranty - parts - 3 years |
Miscellaneous | |
Compliant Standards | RoHS, WEEE, China RoHS, EN 62368-1, UL/CSA 62368-1, IEC 60950-1, VCCI Class A, FCC Class A certified, ICES-003 Class A, EN 55032 Class A, CISPR 32 Class A, EN 61000-3-2, EN 61000-3-3, CISPR 24 Class A, AS/NZS CISPR 32 Class A, CNS 13438 Class A, KN32 Class A |
Features | SMTP support, SNMP support |
Included Accessories | Rack mounting kit, 2 x 1.5 m PDU cords |
Power | |
Max Supported Qty | 2 |
Power Device | 2 x internal power supply - hot-plug |
Power Redundancy | Yes |
Power Redundancy Scheme | 1+1 |
Processor | |
CPU | No CPU |
Storage | |
HDD Array External Interface | iSCSI (10 GbE) |
Max Supported Capacity | 92.16 TB |
Total Array Capacity | 3.84 TB |
Storage Controller | |
Cache / Buffer Size (Max) | 24 GB |
Data Transfer Rate | 1.2 GBps |
Installed Qty | 2 |
Interface Type | SAS 12Gb/s |
Max Storage Devices Qty | 240 |
RAID Level | RAID 0, RAID 1, RAID 3, RAID 5, RAID 6, RAID 10, RAID 50 |
Type | RAID (SAS-3) |
Storage Controller (2nd) | |
Installed Qty | 2 |
System Requirements | |
OS Required | Microsoft Windows, SuSe Linux, HP-UX, HP OpenVMS, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2012 R2 with Hyper-V, Red Hat Enterprise Linux, VMware ESXi 5.x, VMware ESXi 6.x, Apple MacOS X |
