P3267-LVE MIC
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
P3267-LVE MIC
| Additional Details | |
|---|---|
| Price: | |
| Mfr Part #: | 02732-001 |
| SHI Part #: | 47723730 |
| Category: | Security cameras |
| UNSPSC: | 46171610 |
| Manufacturer: | Axis Communications |
| Product Type: | Accessories |
| General Information | |
|---|---|
| Category | Security cameras |
| Description | P3267-LVE MIC |
| Manufacturer | Axis Communications |
| UNSPSC | 46171610 |
| Main Specifications | |
| Dimensions & Weight / Depth | 14.9 cm |
| Dimensions & Weight / Height | 10.7 cm |
| Dimensions & Weight / Weight | 900 g |
| Dimensions & Weight / Width | 14.9 cm |
| Header / Brand | Axis |
| Header / Country Kits |
|
| Miscellaneous / Product Color | White |
| Packaged Quantity | 1 |
| Service & Support / Type | 5-year warranty |
| Camera | |
| Digital Video Capture Resolution | 2592 x 1944, 160 x 90 |
| Digital Video Format | H.264, MPEG-4 Part 10, AVC, H.265, MPEG-H Part 2, HEVC, MJPEG |
| Exposure Range | 1/5 sec - 1/33500 sec |
| Features | IR Corrected lens, remote zoom, remote focus, Forensic WDR, Lightfinder 2.0 technology, deep learning processing unit (DLPU), Zipstream technology, digital PTZ function, Adaptive Bitrate (ABR), Multi-Bitrate (MBR), Variable Bitrate (VBR), video streaming indicator, 180° image rotation, 270° image rotation, 90° image rotation, brightness control, compression, contrast control, Corridor mode, day/night threshold, defogging, distortion correction function, dynamic text, exposure zone, image mirror, image overlay, Privacy Mask Function, saturation control, sharpness control, white balance, simplex audio, Axis device ID, Axis Edge Vault, brute force delay protection, centralized certificate management, digest authentication, HTTPs encryption, IP address filtering, password protection, secure boot, secure keystore, signed firmware, signed video, user access log, VAPIX support, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, Pixel Counter Support, human detection, Vehicle Detection, OptimizedIR, memory card encryption, NAS-Ready, up to 2 view areas, -190° / +190° rotation |
| Flash Memory | 8 GB |
| Frame Rate (max) | 30 frames per second |
| Infrared Distance | 40 m |
| Infrared LEDs | Yes |
| Max Digital Video Resolution | 2592 x 1944 |
| Minimum Illumination |
|
| Motion Detection | Yes |
| RAM | 2 GB |
| Type | Color - Day&Night - fixed - outdoor |
| Environmental Parameters | |
| Max Operating Temperature | 50 °C |
| Min Operating Temperature | -40 °C |
| Relative Humidity (operating) | 10 - 100% RH (condensing) |
| Expansion / Connectivity | |
| Encryption Algorithm | TLS 1.2, TLS 1.3 |
| Ports |
|
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| General | |
| Audio Formats | LPCM, AAC-LC, G.711, PCM, G.726, ADPCM, OPUS |
| Audio Support | Yes: two-way audio via edge-to-edge technology, built-in microphone |
| Camera Mount Type | Wall mount, ceiling mount |
| Connectivity Technology | Wired |
| Depth | 14.9 cm |
| Device Type | Network surveillance camera |
| Form Factor | Dome |
| Height | 10.7 cm |
| Localization | United States, United Kingdom, Korea, Japan, India, Europe, China, Brazil, Australia, Argentina |
| Weight | 900 g |
| Width | 14.9 cm |
| Image Sensor | |
| Type | 5 MP PS RGB CMOS 1/2.7" |
| Interfaces | |
| Network Interface | Ethernet 10Base-T/100Base-TX |
| Network Protocols | IPv4, IPv6, USGv6, ICMP, HTTP, HTTPS, TLS, QOS, FTP, SFTP, CIFS, SMB, SMTP, Bonjour, UPnP, SNMP 1, SNMP 2c, SNMP 3, DNS, DDNS, NTP, RTSP, RTCP, RTP, SRTP, TCP/IP, UDP/IP, IGMP, IGMPv2, IGMPv3, DHCP, ARP, SOCKS, SSH, SIP, LLDP, CDP, MQTT, Syslog, Zeroconf |
| Lens Construction | |
| Focal Length | 3 mm - 8 mm |
| Horizontal Field of View (degree) | 40 - 104 |
| Lens Iris | F/1.3 auto iris (P-Iris) |
| Min Focus Distance | 1 m |
| Optical Zoom | 2.6 x |
| Type | Vari-focal |
| Vertical Field of View (degree) | 29 - 74 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Color | White, NCS S 1002-B |
| Compliant Standards | IEEE 802.1x, PVC-free, BFR-free, CFR free, IEEE 802.3af, IEEE 802.3at, EMC, EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 B Class A, ICES-3(A)/NMB-3(A), IEC 62236-4, KN32 Class A, KCC KN35, RCM, AS/NZS CISPR 32 Class A, VCCI Class A, CAN/CSA C22.2 No. 62368-1 Third Edition, IEC/EN/UL 62368-1, IEC/EN 62471, IS13252, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 62262 IK10, NEMA250 Type 4X, NEMA TS-2 (2.2.7-2.2.9), NIST SP500-267 |
| Included Accessories | Drill hole template, RESISTORX T20 screw bit, terminal block connectors, cable gaskets, connector guard, weathershield |
| Panning | |
| Range (degree) | -190 to +190 |
| Power | |
| Power Device | 6.4 Watt |
| Power Requirements | PoE Plus Class 3 |
| Software / System Requirements | |
| Software Included | AXIS Object Analytics, AXIS Video Motion Detection, Windows decoder 1-user license |
| Tilting | |
| Range (degree) | -10 to +80 |
