Dell Networking X1018
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Dell Networking X1018
- Switch
- L2+
- Managed
- 16 x 10/100/1000 + 2 x Gigabit SFP
| Additional Details | |
|---|---|
| Mfr Part #: | 210-AEIK |
| SHI Part #: | 30475814 |
| Category: | Network switches |
| UNSPSC: | 43222612 |
| Manufacturer: | Dell |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Network switches |
| Description | Dell Networking X1018 - Switch - L2+ - Managed - 16 x 10/100/1000 + 2 x Gigabit SFP |
| Manufacturer | Dell |
| UNSPSC | 43222612 |
| Main Specifications | |
| Dimensions & Weight / Depth | 25 cm |
| Dimensions & Weight / Height | 41.25 cm |
| Dimensions & Weight / Width | 20.9 cm |
| Header / Brand | Dell |
| Networking / Ports Qty | 16 |
| Networking / Type | Switch |
| Packaged Quantity | 1 |
| Service & Support / Type | Limited lifetime warranty |
| Dimensions & Weight | |
| Depth | 25 cm |
| Height | 41.25 cm |
| Width | 20.9 cm |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Max Operating Temperature | 45 °C |
| Max Storage Temperature | 70 °C |
| Min Operating Temperature | 0 °C |
| Min Storage Temperature | -20 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| General | |
| Authentication Method | RADIUS, TACACS+ |
| Capacity |
|
| Compliant Standards | IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1p, IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1v, IEEE 802.1x, IEEE 802.3ac, IEEE 802.3ad (LACP), IEEE 802.3x |
| Device Type | Switch - 16 ports - L2+ - managed |
| Enclosure Type | 1U |
| Features | IPv6 support, Head of Line Blocking Prevention, Back Pressure Support, VCT technology, auto-negotiation, Broadcast Storm Control, DHCP server, MLD snooping, port mirroring, QoS, STP support, static routing, UDLD, VLAN support, GVRP, RSTP support, MSTP support, LACP, SNMP support, SNMP trap, TFTP support, Syslog support, SNTP support, DNS server, LLDP support, ACL support, DHCP relay, DHCP snooping, ARP inspection, Proprietary Protocol Filtering |
| MAC Address Table Size | 16K entries |
| Performance |
|
| Ports | 16 x 10/100/1000 + 2 x Gigabit SFP |
| Remote Management Protocol | SNMP 1, SNMP 2, SNMP 3, HTTP, RMON, CLI |
| Subtype | Gigabit Ethernet |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Power | |
| Power Consumption Operational | 21.5 Watt |
| Power Device | Internal power supply |
| Power Provided | 40 Watt |
| Voltage Required | AC 120/230 V (50/60 Hz) |
