ASUS VivoMini VC68V CSM
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
ASUS VivoMini VC68V CSM
- Mini PC
- Core i7 7700 / 3.6 GHz
- RAM 8 GB
- HDD 1 TB
- HD Graphics 630
- GigE
- WLAN: 802.11a/b/g/n/ac, Bluetooth 4.2
- vPro
- Win 10 Pro 64-bit
- monitor: none
| Additional Details | |
|---|---|
| Mfr Part #: | VC68V-G059Z-CSM |
| SHI Part #: | 34858874 |
| Category: | Desktop computers |
| UNSPSC: | 43211507 |
| Manufacturer: | ASUS |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Desktop computers |
| Description | ASUS VivoMini VC68V CSM - Mini PC - Core i7 7700 / 3.6 GHz - RAM 8 GB - HDD 1 TB - HD Graphics 630 - GigE - WLAN: 802.11a/b/g/n/ac, Bluetooth 4.2 - vPro - Win 10 Pro 64-bit - monitor: none |
| Manufacturer | ASUS |
| UNSPSC | 43211507 |
| Main Specifications | |
| Chassis / Form Factor | Small form factor |
| Dimensions & Weight / Depth | 19.63 cm |
| Dimensions & Weight / Height | 4.93 cm |
| Dimensions & Weight / Weight | 2.17 kg |
| Dimensions & Weight / Width | 19.75 cm |
| Display / Type | None. |
| Hard Drive / Capacity | 1 TB |
| Header / Brand | ASUS |
| Mainboard / Chipset Type | Intel Q270 |
| Miscellaneous / Product Color |
|
| Networking / Data Link Protocol |
|
| Networking / Wireless LAN Supported | Yes |
| Networking / Wireless Protocol |
|
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| OS Provided / Type | Windows 10 Pro 64-bit Edition |
| Packaged Quantity | 1 |
| Processor / Clock Speed | 3.6 GHz |
| Processor / Generation | 7 |
| Processor / Manufacturer | Intel |
| Processor / Number of Cores | Quad-Core |
| Processor / Processor Number | I7-7700 |
| Processor / Type | Core i7 |
| RAM / Form Factor | SO-DIMM 260-pin |
| RAM / Memory Speed | 2400 MHz |
| RAM / Technology | DDR4 SDRAM |
| Service & Support / Type | 3-year warranty |
| System / Hard Drive Capacity | 1 TB |
| System / Platform Technology | Intel vPro Platform |
| System / Type | Personal computer |
| Video Output / Graphics Processor | Intel HD Graphics 630 |
| Audio Output | |
| Sound Output Mode | Stereo |
| Cache Memory | |
| Cache Per Processor | 8 MB |
| Installed Size | 8 MB |
| Card Reader | |
| Supported Flash Memory Cards | MultiMediaCard, SD Memory Card, SDHC Memory Card, SDXC Memory Card |
| Type | 4 in 1 card reader |
| Dimensions & Weight | |
| Depth | 19.63 cm |
| Height | 4.93 cm |
| Weight | 2.17 kg |
| Width | 19.75 cm |
| Environmental Parameters | |
| Sound Emission | 19 dB |
| Expansion / Connectivity | |
| Bays | 2 (total) / 1 (free) x internal 2.5" |
| Interfaces |
|
| Slots | 1 (total) / 0 (free) x M.2 Card - 2280 |
| General | |
| Color | Iron gray |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Platform Technology | Intel vPro Platform |
| Product Form Factor | Mini PC |
| Type | Personal computer |
| Graphics Controller | |
| Graphics Processor | Intel HD Graphics 630 |
| Max Monitors Supported | 3 |
| Video Interfaces | HDMI, DisplayPort |
| Hard Drive | |
| Capacity | 1 x 1 TB |
| Interface Type | SATA |
| Spindle Speed | 5400 rpm |
| SSD Cache | 3D Xpoint (Optane) - 16 GB |
| Type | HDD |
| Input Device | |
| Type | Mouse, keyboard |
| Keyboard | |
| Interface | USB |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years - pick-up and return |
| Miscellaneous | |
| Compliant Standards | UL, VCCI, BSMI, CB, FCC |
| Security Slot Type | Kensington security slot |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| VESA Mounting Interface | Yes |
| Monitor | |
| Monitor Type | None. |
| Mouse | |
| Interface | USB |
| Networking | |
| Compliant Standards | Wi-Fi CERTIFIED |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 4.2 |
| Ethernet Controller | Intel I219-LM |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Dual Band Wireless-AC 8260 |
| Operating System / Software | |
| OS Provided | Windows 10 Pro 64-bit Edition |
| Optical Storage | |
| Type | No optical drive |
| Power | |
| Device Type | Power adapter |
| Power Provided | 120 Watt |
| Processor / Chipset | |
| Chipset Type | Intel Q270 |
| Clock Speed | 3.6 GHz |
| CPU | Intel Core i7 (7th Gen) 7700 |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Max Turbo Speed | 4.2 GHz |
| Number of Cores | Quad-Core |
| Processor Main Features | Intel Turbo Boost Technology 2 |
| RAM | |
| Configuration Features | 1 x 8 GB |
| Effective Memory Speed | 2400 MHz |
| Features | Dual channel memory architecture |
| Form Factor | SO-DIMM 260-pin |
| Installed Size | 8 GB / 32 GB (max) |
| Rated Memory Speed | 2400 MHz |
| Slots | 2 (total) / 1 (empty) |
| Technology | DDR4 SDRAM |
| Storage Controller | |
| Controller Interface Type | SATA 6Gb/s |
| Type | 1 x SATA |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
