WD Ultrastar SN200 HUSMR7616BHP301
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
WD Ultrastar SN200 HUSMR7616BHP301
- SSD
- 1.6 TB
- internal
- PCIe card (HHHL)
- PCIe 3.0 x8 (NVMe)
| Additional Details | |
|---|---|
| Mfr Part #: | 0TS1305 |
| SHI Part #: | 36988041 |
| Category: | Hard drives |
| UNSPSC: | 43201803 |
| Manufacturer: | Western Digital |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Hard drives |
| Description | WD Ultrastar SN200 HUSMR7616BHP301 - SSD - 1.6 TB - internal - PCIe card (HHHL) - PCIe 3.0 x8 (NVMe) |
| Manufacturer | Western Digital |
| UNSPSC | 43201803 |
| Main Specifications | |
| Dimensions & Weight / Depth | 68.9 mm |
| Dimensions & Weight / Height | 14.49 mm |
| Dimensions & Weight / Weight | 230 g |
| Dimensions & Weight / Width | 167.65 mm |
| Hard Drive / Capacity | 1.6 TB |
| Hard Drive / Form Factor | PCIe card (HHHL) |
| Hard Drive / Hard Drive Type | Internal hard drive |
| Hard Drive / Interface | PCI Express 3.0 x8 (NVMe) |
| Hard Drive / Interface | PCI Express 3.0 x8 (NVMe) |
| Header / Brand | WD |
| Miscellaneous / Product Color | Black |
| Packaged Quantity | 1 |
| Service & Support / Type | 5-year warranty |
| Storage / Type | Solid state drive |
| Environmental Parameters | |
| Max Operating Temperature | 55 °C |
| Min Operating Temperature | 0 °C |
| Expansion & Connectivity | |
| Compatible Bay | PCIe card (HHHL) |
| Interfaces | 1 x PCI Express 3.0 x8 (NVMe) |
| General | |
| Capacity | 1.6 TB |
| Depth | 68.9 mm |
| Device Type | Solid state drive - internal |
| Features | Secure Erase function, PowerSave technology, End-to-end data path protection, Online Transaction Processing (OLTP), Advanced ECC Engine, Online Analytical Processing (OLAP), NVM Express (NVMe), High Frequency Trading (HFT), flash-aware RAID |
| Form Factor | PCIe card (HHHL) |
| Height | 14.49 mm |
| Interface | PCIe 3.0 x8 (NVMe) |
| Weight | 230 g |
| Width | 167.65 mm |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Compliant Standards | REACH, RoHS 2 (2011/65/EU) |
| Performance | |
| Average Latency | 20 µs |
| Drive Writes Per Day (DWPD) | 3 |
| Internal Data Rate | 6170 MBps (read) / 2200 MBps (write) |
| Maximum 4KB Random Read | 1200000 IOPS |
| Maximum 4KB Random Write | 200000 IOPS |
| Power | |
| Power Consumption |
|
| Reliability | |
| MTBF | 2,000,000 hours |
| Seek Errors | 1 per 10^17 |
